THE AKAR
The AKAR 1000- Precision Beyond Boundaries: Large-Scale, Smart, and Seamless 3D Printing
KEY FEATURES OF THIS PRINTER
- 1050x1050x1250mm (reg), 1050x1050x1200mm (high flow)
- User Friendly User Interface
- Touch Screen for Standalone printing
- SD Card & WiFi connectivity
- Filament Supply Sensing
- Power Outage Recovery
- High-Resolution prints with Heated bed
- Multiple Printable materials
Get to know the AKAR PRO 3D Printer
7″ Full Colour Touch UI
Experience precise control with our 7″ touchscreen—intuitive, simple, and optimized for 3D printing
Range of filaments
PLA / ABS / TPU / PETG / PVA / Glass Fiber Infused / Carbon Fiber Infused / Metal Fill / Wood Fill and more
AC Heated Bed
100 º C in just 5 minutes (800 Watt)
Filament Run-out Sensor
When the filament runs out, the printer will trigger an alarm and, as a result, pause the printing process. Therefore, you get a worry-free printing experience.
Hiwin HGR15C XY Linear Motion
Perfect linear motion for XY axes helps the machine to achieve perfect 3D prints.
Dual Extrusion System
Print soluble support materials
Unibody Metal Design
Crafted with Precision: Our Unibody Metal Design offers a seamless, sturdy, durable frame. Experience sophistication and strength in one singular form.
CNC Machined Parts
The XY motion system sits on CNC-milled blocks, ensuring perfect perpendicularity for consistent dimensional accuracy.
Ball Screw for Z-Axis
Helps in smooth and long life of Z-axis motion system
| TECHNICAL SPECIFICATIONS | |
|---|---|
| Build Volume (WxDxH) | 1050x1050x1250mm (reg), 1050x1050x1200mm (high flow) |
| Machine Size (WxDxH) | 1800x1450x1800 mm |
| Print Technology | FDM/FFF |
| Packing Size (WxDxH) | 1750x1750x1100 mm |
| No. of Extruders | Single / Dual (Modular, Optional Pellet Extruder) |
| Printing Speed | 30-300 mm/s (30-200 mm/s recommended) |
| Build Plate Type | Aluminum Plate with Toughened Glass, Optional: PEI Sheet |
| Max Build Plate Temp. | 120ºC |
| Heating Bed Element | Silicone Heater |
| Filament Compatibility | PLA / TPU / TPE / PETG / PVA / Glass Fiber Infused / Carbon Fiber Infused / Metal Fill / Wood Fill / Nylon / PC (Optional Pellets) |
| Max Nozzle Temp. | 300ºC |
| Max Power Usage | 3000 W |
| Supported File Format | GCODE & UFP |
| Supported Software | Mekuva Slicer, Simplify3D, Cura, Orca, PrusaSlicer |
| Product Weight | 350 Kg |
| Box Weight | 450 Kg |
| Supported Spool Sizes | 1 Kg, 1.5 Kg, 2.5 Kg, 5 Kg |
| Compatible Nozzle Sizes | 0.4, 0.5, 0.6, 0.8, 1.0, 1.2 mm |
| Bed Leveling | Automatic Mesh Levelling, 36-point leveling |
| Printer Display (Control) | 7″ Full Colour Touchscreen with IoT Smart Connectivity |
| Complementary Accessories | Scraper, Side cutter, Nose pliers, Nozzle changing wrench, Glue stick, Extra heater and thermistor, Hotend setup, Pendrive, Spirit level, Allen key set, Extra nozzles, 1 Kg PLA Filament, and extra screws. |
